Pratissoli KS36A Series Plunger Pumps

Features:

• GPM= 48.3
• PSI= 2350
• RPM= 1200
• Bore= 36 mm
• Stroke= 50 mm
• BHP= 77.7
• Weight= 209 lbs.
• Non-elastic crankshaft with flame hardened journals.
• 420 stainless steel, nickel coated manifold, special aluminum alloy connecting rods, cast aluminum symmetrical crankcase.
• Solid ceramic plunger, lubricated high and low pressure seal system.
• Available with external gear reducer for direct drive applications.
• Specify RPM when ordering.
• Use NG for units without gearbox.
• Max. Inlet Pressure: 45 psi
• Max. Fluid Temperature: 140° F
• Inlet Port Thread: 2 NPT-F
• Discharge Port Thread: 1-1/2 NPT-F
• Oil Capacity: 128.5 fl oz
• Shaft Diameter: 40 mm
• Pump Dimensions: 23" x 19" x 10.3"

Construction:

Triplex plunger pump, available in 4 versions. Patent pending, symmetrical power end design featuring top and bottom mounting holes allowing for easy left to right shaft conversion. Low-high pressure packing design with integrated cooling system. high volumetric efficiency suction/delivery valves featuring new spherical design of sealing areas. Splash lubrication. External gearbox available in 3 ratios and positionable on left or right side of the pump. Flushing systems available on request on selected versions.
